Intelligent Car Bottom Inspection Instrument

Product Name Intelligent Car Bottom Inspection Instrument
Mini Order 1 set
FOB Price
Paymnet T/T, Paypal, WestUnion
Supply Ability 500 sets / month
Dilivery Time Depend on quantity
Package Carton package

Product Description







wps-1516dskc-c58pt Car Bottom Safety inspection mirror, intelligent car Bottom inspection instrument, video car bottom inspection instrument, storage type video car bottom inspection instrument


I. Product INTRODUCTION

WPS-1516DSKC-C58PT-type Car bottom video detector is a multi-functional new product, it can display four directions of the image, expand the field of vision, moving and fixed two types of detection mode, the vehicle bottom contraband security checks, for the vehicle at the bottom of the security check, Can be installed in the vehicle to allow access to the entrance or various types of access to the vehicle at the bottom of the image collection, to determine whether the bottom of the vehicle to install bombs, drugs and other prohibited items. The product has DVR video function, it is convenient to store images to the SD card backup, so that security personnel to quickly check, improve efficiency. The product is applicable to the airport, dock, customs, prisons, military restricted zones, hotels and other security areas of the car chassis inspection.

Second, the characteristics of the product

1, 15-inch color display, multinational language settings. The results of the examination are clearer.

2, 4 high-definition Sony camera in different directions, multi-angle and multiple images to see things,

3, the Instrument automatic high brightness 12V LED light to fill the light, in the case of insufficient light, you can give the camera to fill the light, so that the view of things more clearly. The brightness of the fill light can be adjusted

4, video inspection results can be recorded. The results of the inspection can be viewed repeatedly and saved for retention.

Third, the technical parameters of products

1, monitor, SD card digital video recorder, power supply

Monitor

15 "inch Color LCD Monitor

Resolution:

1280x1024

Multi-national Language menu

SD Card Digital Recording camera

Video format

AVI

Storage media

SD Card

Power
Dc 12V

Frame rate

Pal:25 Frames/sec, ntsc:30 frames/sec

Resolution

d1:720x576

qvga:360x288

Compressed format

M-JEPG & Standard JPEG

Reconnaissance mode

Motion detection

Working mode

Video/Photo

Memory

SDHC card, ≤32GB

Power

DC12V (5v-36v can be customized)

Working current

≤250ma

Operating temperature

-10℃~+50℃

Working humidity

20%~85%

2, Camera


(1) This instrument has 4 cameras: Sony, Pixel CS (dpi), model g639+s3172+2096 type CCD motherboard image sensor 1/3-sony COLOR level sharpness (TVL, Minimum illuminance 0.1 (Lux), resolution 480TV lens CS (mm), signal-to-noise ratio > (db), backlight compensation AUTO, size 1/3 (inches), can be more than the angle of the picture to see things.

(2) The instrument is also equipped with a light source is a high brightness 12V LED lights to fill the light, in the case of insufficient light, you can give the camera to fill the light, so that the view of things more clearly. The brightness of the fill light can be adjusted.

3, four-way color video processor parameters

4. Working voltage: dc12v (rechargeable)

5, connecting rod Length: 1.3 meters

6, Camera base device height: 9.5cm

7, operating temperature: -10℃-+50℃ (℃)

8. Net Weight: 8.6Kg

9, Gross Weight: 15.1Kg

10, Size: monitor: 46.6*19* 38.5cm

Fuselage Packaging: 74*42* 7cm (Aluminum box packaging)

Iv. Scope of application

This product is divided into mobile and fixed two types of detection mode, the vehicle bottom contraband safety inspection, for the vehicle bottom security checks, can be installed in the permitted vehicles to pass the entrance or access to various types of access. and recording and archiving the results of the inspection. Easy to access at any time.
